Magnetic Sensor PE-905

Magnetic Proximity Switch

• Model No.   : Pe-905
• Contact Rating        :  10

• Switching Voltage    :  200Vdc)
• Breakdown Voltage       :  250(Vdc)
• Switching Current    :  500(Mamp.)
• Contact Resistance      :  150(Mohm)
• Operating Time     :  1.0(Msec.)
• Operating & Storage Temp.   :  -25To +75
• Must Operating Dis.      :  59(Mm Max.)
• Must Release Dis.      :  15(Mm Min.)
• Approval   :  Ce Approved

Magnetic Proximity Switches  Are Used To Detect The Magnetic Field. It Consist Of Two Parts,  One Is The Sensor And Other Is Actuator. Magnetic Proximity Sensors Makes Ancillary Power Unnecessary And Makes The Sensors And Actuator Combination The Cost Effective Selection When Compared To Other Sensing Technologies. Some Applications Of Magnetic Proximity Switches Are-Limit Switching, Machine Tool Position Sensing, Valve Position Sensing, Food Processing Machinery, Revolution Sensing, Elevetor Position Sensing Etc.Magnetic Security Switch Or Magnetic Contacts  Are The Same As Magnetic Proximity Switches Only The Difference Is The Mechanical Dimensions. Magnetic Contacts  Are Used As A Door Switch , Rolling Shutter And Many Mo
