Magnetic Door sensor PE-915

Get a Price/Quote

Magnetic Door sensor PE-915 Specification

Max. Current
250AMP Ampere (amp)

Product Type
Magnetic switches

Material
Plastic & Metals

Insulation Resistance
Yes

Max. Voltage
100VDC Volt (V)

Size
21x31x11mm

Color
Multicolor

Magnetic Door sensor PE-915 Trade Information

Minimum Order Quantity
05 Pieces

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
International norms. Each piece is packed in separate bubble polythene bag and then in individual corrugated box. As per

Main Domestic Market
All India

Certifications
CE APPROVED

About Magnetic Door sensor PE-915

Magnetic Proximity Switch

Model No : Pe-915
Contact Rating : 5
Switching Voltage : 100(Vdc)
Breakdown Voltage : 125(Vdc)
Switching Current : 250(Mamp.)
Contact Resistance : 75(Mohm.)
Operating Time : 1.0(M Sec.)
Operating & Storage Temp : -25To +75
Must Operating Dis. : 5(Mm Max.)
Must Release Dis. : 7-8(Mm Min.)
Approval : Ce Approved

Magnetic Security Switches

Magnetic Proximity Switches Are Used To Detect The Magnetic Field. It Consist Of Two Parts, One Is The Sensor And Other Is Actuator. Magnetic Proximity Sensors Makes Ancillary Power Unnecessary And Makes The Sensors And Actuator Combination The Cost Effective Selection When Compared To Other Sensing Technologies. Some Applications Of Magnetic Proximity Switches Are-Limit Switching, Machine Tool Position Sensing, Valve Position Sensing, Food Processing Machinery, Revolution Sensing, Elevetor Position Sensing Etc.Magnetic Security Switch Or Magnetic Contacts Are The Same As Magnetic Proximity Switches Only The Difference Is The Mechanical Dimensions. Magnetic Contacts Are Used As A Door Switch , Rolling Shutter And Many More
