Photo Electric Proximity Switches (Diffused type)

Photo Electric Proximity Switches (Diffused type)
Photo Electric Proximity Switches (Diffused type)
Product Code : PE-2D-18-N1-10
Brand Name : PARAS
Product Description

   photo Electric Proximity  Switch

   Model No.--------------PE-2D-18-N1-10

1.       Size     : M-18x72
2.       Type    : Npn
3.       Output Logic    : No
4.       Operating Voltage     : 10-30 Vdc
5.       Max. Load Current     : 300 Mamp.
6.       Sensing Distance       : 200 Mm Adj. For Standard Object Size
7.       Switching Frequency     : 500 Hz.
8.       Position Indication     : Led
9.       Cable   : 3 Core Pvc & Pu Flexible
10.   H.V. Test    : 1.5 Kv For 1 Sec.
11.   Ambient Temp.    : 700 C
12.   Enclosure    : Nickel Platted Brass Tube
13.   Probe Size   : 18x72
14.   Approvals      : Ce
15.   Standard object Size   : 20x20x1

Photo Electric Proximity Switches Or Sensors Are Primarily Used When The Object To Be Sensed Is  metallic Or Non Metallic.  Photo Electric Sensors Are Three Defferent Types.

  1. Diffused Type Photo Electric Proximity Switch,

  2. Through Beam Type Proximity Switch

  3. Retro refrective  Type Proximity Switch.

Working Principal

  1. Diffused Type

These Type Of Proximity Switch Are Contned Emitter And Receiver In One Unit.

When The Emitter Emites The Infrared Signal Which Is Reflected From The Surface Of The Object To Be Detected And Received By The Receiver And This Will Changed The Output Stage.
