Magnetic Proximity Switch PE-903

Magnetic Proximity Switch PE-903
Magnetic Proximity Switch PE-903
Product Code : PE-903 with LED
Brand Name : PARAS
Product Description

Parasnath Electronics is a leading manufacturer, supplier, whole seller and exporter of a diversified range of Magnetic Proximity Switches.

Product specification:- Model No.--------PE-903 (With LED Indication)

1.     Contact Rating                                     :  20

2.     Switching Voltage                                 :  300(VDC)

3.     Breakdown Voltage                              :  375(VDC)

4.     Switching Current                                 :  750(mAMp.)

5.     Contact Resistance                               :  100(mOhm.)

6.     Operating Time                                     :  2.0(mSec.)

7.     Operating & Storage Temp.                  : -25To +75

8.     Must Operating Dis.                             :  4(mm Max.)

9.     Must Release Dis.                                 :  15(mm min.)

10. Approval                                              :  CE Approved

 MAGNETIC PROXIMITY SWITCHES  ARE USED TO DETECT THE MAGNETIC FIELD. IT CONSIST TWO PART ONE IS THE SENSOR AND OTHER IS ACTUATOR. MAGNETIC PROXIMITY SENSORS MAKES ANCILLARY POWER UNNECESSARY AND MAKES THE SENSORS AND ACTUATOR COMBINATION THE COST EFFECTIVE SELECTION WHEN COMPARED TH OTHER SENSING TECHNOLOGIES. SOME APPLICATION OF MAGNETIC PROXIMITY SWITCHES ARE-LIMIT SWITCHING, MACHINE TOOL POSITION SENSING, VALVE POSITION SENSING, FOOD PROCESSING MACHINERY, REVOLUTION SENSING, ELEVETOR POSITION SENSING ETC.
